The Industrialist’s Golden Ratio: The Force That Drives the Workshop
The Mekotek MKT 32135 Press Brake is the first and most essential machine that must be brought in when setting up a metalworking shop. Known in the industry as the “3-meter machine,” this size forms the backbone of production because it can process all standard sheet metal sizes available on the market. With its 135-metric-ton bending force, it effortlessly bends not only thin sheet metal but also black sheet metal up to 6–8 mm thick from end to end. If you’re looking for a tireless “jack-of-all-trades” for your workshop, this machine is perfect for you.
No More “Banana Effect”: Motorized Bombing Technology
The biggest problem encountered when bending a 3.2-meter-long sheet is that the machine body flexes, causing the center of the part to protrude at a different angle than the edges (in a banana-shaped manner). On smaller machines, this can be corrected by hand, but it’s difficult with a 3-meter part. The Motorized Crowning system, which we offer as standard on the MKT 32135, solves this problem at its root. The CNC unit calculates how much deflection will occur based on the part you’re bending and automatically inflates the lower platen using motors. Your operator no longer needs to manually compress the paper or make adjustments; the thousandth part will come out just as perfectly as the first.
8-Ton Giant Chassis, Precision German Technology
With a body weighing 8,300 kg (8.3 metric tons), this machine stands firmly on the ground. It does not flex like lighter machines. It draws its power from the world-renowned Bosch Rexroth hydraulic system. As a result, the machine operates with the same precision whether it’s cold in the morning or warm in the evening. The Cybelec CybTouch 12 control unit allows your operator to sketch the part on the screen and automatically generates the bending sequence. With its Y1, Y2, X, and R-axis configuration and the DSP Laser Safety System, you can achieve both fast and safe production.
Why Mekotek? Insurance for Your Production Line
The press brake is the heart of the workshop; if it stops, so do your welders and your assemblers. At Mekotek, we stand behind every single bolt of the machines we manufacture in our 30,000-square-meter factory. With us, you won’t face the scenarios common with imported machines, such as “the circuit board burned out, and the replacement part won’t arrive for another month.” Every part—from the hydraulic seals to the electronic circuit boards—is readily available in our inventory. Working with us means securing your production line and sleeping soundly at night.
MKT 32135 Technical Specifications
|
FEATURES |
|
|---|---|
|
Model |
MKT 32135 |
|
Bending Force |
1350 KN |
|
Bending Capacity (metric tons) |
135 Ton |
|
Power Supply |
3PH / 380V / 50 HZ |
|
Coil Length (mm) |
3200 mm |
|
Table Height |
900 mm |
|
Distance Between Walls |
2500 mm |
|
Strait Depth |
400 mm |
|
Strok |
200 mm |
|
Center-to-Center Distance |
470 mm |
|
Descent Rate (mm/s) |
180 mm/s |
|
Rotational Speed (mm/s) |
140 mm/s |
|
Bending Speed (mm/s) |
10 mm/s |
|
X Axis Stroke |
550 mm |
|
X Axis Movement Speed |
400 mm/s |
|
X Axis Positioning Accuracy |
± 0.05 mm |
|
X Axis Repositioning Accuracy |
± 0.02 mm |
|
Y Axis Positioning Accuracy |
± 0.02 mm |
|
Y Axis Repetability |
± 0.01 mm |
|
R Axis Stroke |
150 mm |
|
Maximum Operating Speed of the R Axis |
100 mm/s |
|
Operating Accuracy: Straight Line |
± 0.2mm/m, Angle: ± 0.5 °/m |
|
Number of CNC Axes |
4+2 axis |
|
Engine Power |
11 KW |
|
Oil Tank Capacity |
200 L |
|
Machine Dimensions |
4000 x 1750 x 2860 mm |
|
Machine Weight |
8300 kgs |
MKT 32135 Main Configuration
|
Feature |
|
|---|---|
|
Control System |
CT12 |
|
Hydraulic System Valve Assembly |
Rexroth |
|
Servo Motor |
Inovance |
|
Oil Pump |
First (U.S.) |
|
Oil Cylinders |
HY |
|
Main Engine |
Inovance |
|
Protection Method |
Mechanical Protection |
|
Control Axes |
4+2 axis |
|
Magnetic Ruler |
Givi (Italy) |
|
X Axis Linear Guide |
HIWIN |
|
X Axis Linear Bar |
HIWIN |
|
Electrical Equipment |
Schneider |
|
Schedule |
Double-Sided Quick-Release Clamp |
|
Workbench |
SRJM |
|
Security Curtain |
DSP/A200 (Including Black Bracket) (Italy) |
|
Security Doors |
Safety Gates |
MKT 32135 Standard Configuration
|
Feature |
|
|---|---|
|
CNC System |
1 set |
|
Rear Support Positioning Fingers |
4 pieces |
|
Standard Top Mold |
1 set |
|
Standard Lower Mold |
1 set |
|
Foot Pedal |
1 set |
|
Toolboxes |
1 set |
